EBMPAPST AXIAL FAN MOTOR

230VAC 30W (60HZ.) 33000 RPM (60HZ.)

SIZE 143 MM. 490 M3/HR. BALL BEARINGS

EBMPAPST FAN MOTOR - SIZE 143 MM. 230VAC 30W (60HZ.) 33000 RPM (60HZ.)

Catalog number 035020109

Manufacturer number W2E143-AB-09-01

Country of origin HU

HS number 84145925

Delivery stock products within 1-2 working days
Free delivery Netherlands > € 350,00 net
High stock level compressor spare parts
Registered THIMAR customers only

Product information "EBMPAPST AXIAL FAN MOTOR "

Material/Surface

Housing: Metal

Impeller: Metal

Characteristics

Version: Classic AC fan; compact and robust

Direction of air flow: exhaust over struts

Direction of rotation: counterclockwise,

Looking towards rotor

Installation position: any

Bearing: Ball bearings

Operating mode: Continuous operation (S1)

IP protection class: IP20

Electrical hookup: via 2 flat plugs 2.8 x 0.5 mm;

Grounding lug for M4 x 6

Electrical protection class: I (with customer connection to grounding conductor)

Weight: 1.0 kg

Approvals: EN 60335-1; CE; UKCA; VDE; UL 507; CSA 22.2 Nr. 113; EAC; A + B + D : CCC on request
